             Location Beacon Module | HY-BI202













    Features
    Dual-channel design, single and double channels can be configured independently
    Intrinsically safe design, can be used with explosion-proof certification
    Ultra-long distance, single base station positioning
    Rich external interfaces, flexibly expandable, supporting Bluetooth 5.0





    Specifications
    Technical specifications
    Parts List
    structure size

    Hardware specifications
    UWB standard
    Bluetooth
    Output power

    Wireless interface

    Storage

    802.15.4a, ch2
    5.0
    Maximum power > -21dBm/MHz (adjustable by software)
    UWB: 2xMMCX connector (side plug/direct plug optional)
    Bluetooth: IPEX4
    nor flash: 32Mbit
    nand flash: 1G or more (8mm*6mm)

    Power consumption parametersCurrent
    Average current: 400mA
    Startup current: 500mA Emission current: 600mA
    Software Specifications
    Positioning mode
    UWB effective distance
    User capacity
    Positioning scenario
    Positioning frequency
    oF
    1400 meters @ 850Kbps (dual antenna) without obstruction and interference; 700 meters @ 850Kbps without obstruction and interference
    Small area: 200 @ 1Hz
    System capacity: unlimited
    0D + 1D + 2D
    Fixed frequency can be set: 10Hz, 5Hz, 2Hz, 1Hz, 0.5Hz, 0.2Hz, 0.1Hz
    Physical specificationssize
    weight
    55*35*11mm (including antenna seat)
    ＜40
    reliability
    Working temperature
    Storage temperature
    Working humidity
    Anti-static level

    -40℃~85℃
    -40oC~85oC
    0%～95% non-condensing
    15KV, contact: 8KV
    Compatible





    Applications
    The construction environment of tunnels, underground rail transit, and mines is harsh and harsh, with frequent accidents and complex management. During the construction process, there is an urgent need for a management system that can ensure the safety of construction workers, realize the modernization and informatization of management, and improve the management efficiency of workers. At the same time, Ensure personnel safety.
    learn more
    Realize the modernization and informatization of management, improve the management efficiency of workers, and ensure the safety of personnel at the same time.
    learn more
    Tunnel corridor
    the traffic
