1D Location Beacon | HY-BI101
Features
Specifications
Applications
1D Location Beacon | HY-BI101
| Performance Parameters |
UWB communication distance Wi-Fi communication distance Bluetooth communication distance Highest positioning accuracy |
≥100m, ≥400m (one-dimensional Mesh mode) ≥10m ＜30cm |
|---|---|---|
| Electrical parameters | Power input Power consumption | 16.8VDC/36VAC ＜5W |
| Antenna parameters | Antenna Type | High performance omnidirectional antenna |
| Environmental parameters | Operating temperature Storage temperature Operating temperature | -30℃ ∽ +75℃ -40℃ ∽ +80℃ 5% ∽ 95%(non-condensing) |
| Fire performance | Protection level Fire protection level Anti-static level | - IP67 UL94-V0 IEC61000-4-2 Standard Level 4 |
| Name | quantity | -1 | -02 | Remark |
|---|---|---|---|---|
| Host | 1 | yes | yes | |
| Screws | 5/13 | 5（pcs） | 13（pcs） | Cross plate, stainless steel nickel plated |
| Expansion screws | 1 | yes | yes | Stainless steel 304, nickel-plated |
| Connector | 1 | yes | yes | 8-pin connector, 8-core cable (power adapter is connected by default) |
