| Performance parameter | Positioning Accuracy Orientation Accuracy Mechanical Tilt Accuracy Time to First Fix Time to First Orientation | Horizontal: Resolution 1e-7°, tolerance ±10 cm (RTK, open and interference-free environment) Vertical: Resolution 1e-7°, tolerance ±10 cm (RTK, open and interference-free environment) Resolution 0.1°, tolerance ±0.5°; range: 0°–359.9° Resolution 0.1°, tolerance ±0.5°; range: ?90° to +90° 5 min (open and interference-free environment) 5 min (open and interference-free environment) |
|---|---|---|
| Reliability index | Operating temperature Storage temperature Working humidity Waterproof class Antistatic class Lightning protection level | -40℃ ∽ +80℃ -40℃ ∽ +85℃ 95%(non-condensing) IP67 IEC 61000-4-2 Standard level 4 IEC 61000-4-5:2005 (IEC 61000-4-5 Current Pulse Profile, 8/20μs, 3kA, 10 repetitions). Power cable: 5kA; Signal cable: 3kA |
| Physical parameter | dimension weight | 510*130*49.5 (Without connector) ＜1200g |
| Electrical parameter | Electrical index | Power consumption < 2W (under normal operation) |
